Product Detail

The long service life and optimum performance translate into lower operating costs.

Maximum resistance to erosion and attrition minimizes the possibility of catalyst contamination.

Extraordinary ability to withstand extreme thermal shock without breaking.

High crush strength permits using deep beds.

Better impact resistance.

Withstands rapid depressurization.

Be free of sulfur, boron and other common catalytic poisons.







Chemical composition

	SM100	SM120
SiO2	>75%	68-73%
Al2O3	15-21%	>23%
Fe2O3	<1%	<1%
CaO	<0.5%	<0.5%
MgO	<0.5%	<0.5%
K2O+Na2O	<4%	<2-4%
Leachable Iron	<0.1%	<0.1%





Typical Properties

	SM100	SM120
Specific gravity g/cm3	2.3-2.4	2.3-2.4
Acid Resistance %	99.6	99.6
Max. Operation Temp.	982	982
Moh’s Hardness Scale	>6.5	>6.5
Bulk Density kg/m3	1.35-1.4	1.35-1.4
Water Absorption	<1%	<1%



Crush strength

	SM100	SM120
1/8’’ (3mm)	>30	>35
1/4’’ (6mm)	>60	>80
3/8’’ (10mm)	>170	>200
1/2’’ (13mm)	>306	>320
3/4’’ (19mm)	>430	>542
1’’ (25mm)	>635	>900
1.5’’ (38mm)	>910	>1000
2’’ (50mm)	>1000	>1360
